1000Kg/h Stainless Steel TPU Industrial Desiccant Dehumidifier
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | JIN MACHINE |
| Certification: | CE;SGS;ISO9001 |
| Model Number: | CSG-3000 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard wooden frame and wooden case is available for Jin Machine Excellent Rigid Packaging drying dryer for plastic recycling |
| Delivery Time: | 25 work days |
| Payment Terms: | T/T, L/C, D/A, D/P, Western Union, MoneyGram |
| Supply Ability: | 10 sets per month |
|
Detail Information |
|||
| Throughput: | 1000Kg/h | Material: | SUS 304 |
|---|---|---|---|
| Controler: | Simens PLC | Dew Point: | -60℃ |
| Production Period: | 30 Days | Product: | Plastic Material Dryer |
| Highlight: | TPU Industrial Desiccant Dehumidifier,1000Kg/h Industrial Desiccant Dehumidifier,Stainless Steel TPU Desiccant Dehumidifier |
||
Product Description
Stainless Steel TPU Industrial Desiccant Dehumidifier Grey / White Color
1.Product Description
CSG series is a fully automatic drying system with zeolite desiccant beds, which can be used with Hopper Bank Series and multi-hopper systems. It can adapt and automatically control operating parameters in line with type and quantity of polymer.Up to 40% energy saving in comparison with traditional dryers
1. Self-adaptive PID temperature control from 60℃ to 300℃
2. No use of cooling water
3. No moving or rotating internal parts
4. No need of manual control, Full auto-adaptive operation
5. Diagnostic functions,Dewpoint, heater and temperature alarm 8.Visual and audible alarms available
6. Anti-stress function protecting polymers against overheating
7. Sturdy, well proven design for extended operational life
8. Visual and audible alarms available
9. Automatic dew point control system: not switch to new desiccant bed before the dew point gets -30°C
2.Main Technical Parameters
| Model | CSG-315 | CSG-800 | CSG-1600 | CSG-3200 | CSG-5000 | CSG-8000 |
| Volume(L) | 315 | 800 | 1600 | 3200 | 5000 | 8000 |
| Capability(kg) | 200 | 500 | 1000 | 2000 | 3000 | 5000 |
| Dry Fan(KW) | 3 | 5.5 | 7.5 | 18.5 | 22 | 33 |
| Rebirth Fan(KW) | 0.37 | 1.1 | 1.5 | 3 | 4 | 4 |
| Drying Heating(KW) | 15 | 24 | 36 | 54 | 63 | 96 |
| Rebirth Heating(KW) | 7.5 | 12 | 18 | 27 | 36 | 36 |
3.CSG plus 3000-5000 series
Zeolite tribler design with three desiccant cartridges and three pump technology: two dedicated to process air production and one for saturated tower regeneration for a continuous dry air flow, automatic regeneration and cooling phase.
1. High-performance 3-bed
2. Three pumps
3. Dew point -30℃ to -70℃, dewpoint monitor
4. Dedicated to large-scale production up to 1200kg/h
4.FAQ
Q1: Which city are you in? How can I get to your factory? Are you a trading company or factory?
A1: We are in Zhangjiagang city, two hours driving from Shanghai. We are a factory, manufacturing mainly plastic dryer machines. We offer turnkey solutions including conveying, drying and mixing with more than 10 years experience.
Q2: Why is your prices higher than others?
A2: We offer high-end machines in our business. Welcome to our factory to have a visit. And you will see the difference.
Q3: What is your delivery time?
A3: Normally no more than 40 working days.
Q4: How to install my machines when it arrives? How much the cost?
A4: We will send our engineers to your factory to install the machines and train your staff how to operate the machines If needed. Or you can arrange engineers to study in our factory.
You are responsible for air tickets, accommodation and our engineer wage USD100/day/person.
Q5: How about the spare parts?
A5: We will send one year enough easy broken spare parts together with the machines for free, we suggest you buy more units to save international courier such as DHL, it is really costly.
Q6: What is your payment term?
A6: 30%T/T in advance as down payment, rest should be paid before shipping. L/C is supported also
