Anti Rust 380V 50Hz 500kg/H Pet Bottle Flakes Machine
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | JIN MACHINE |
| Certification: | CE Certificate |
| Model Number: | JIN-75A |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard wooden frame and wooden case is available for Jin Machine Excellent Rigid Packaging drying dryer for plastic recycling |
| Delivery Time: | 45 work days |
| Payment Terms: | T/T, L/C, D/A, D/P, Western Union, MoneyGram |
| Supply Ability: | 10 sets per month |
|
Detail Information |
|||
| Application: | PET Granulating | Material: | 304 Stainless Steel |
|---|---|---|---|
| Raw Material: | PET Flakes Or Bottles | Motor: | Siemens Brand |
| Warranty: | 12 Months | Production Period: | 55 Days |
| Capacity: | 100-800 Kg/h | ||
| High Light: | 500kg/H Pet Bottle Flakes Machine,50Hz Pet Bottle Flakes Machine,380V Pet Bottle Flakes Machine |
||
Product Description
Anti Rust 380V 50Hz 500kg/H Pet Bottle Flakes Machine
Plastic PET Granulating Machine 500kg / H PET Bottle Flakes Recycling
1. Introduction
We are Jin Machine, we are a modern family-owned enterprise. Which contains two mechanical manufacturing companies. Jinguan and Jinyue. Jinguan was established in 2006, focusing on mechanical design; Jinyue was established in 2017, focusing on research and development of drying and central conveying. Through 13 years of experience and technical accumulation, Jin Machine now offers a single machine or a complete set of centralized feeding, compounding, recycling and drying systems. We have excellent mechanical control, ultra-low energy consumption which is comparable to imported equipment. Besides, our fast after-sales response can let our customers get asuperb service experience.
2. Product Application
PET granulator machine is good for reducing the plastic degradation, granulating better pellets, which is really a good choice for the customers in PET recycling.
Besides, this machine is easy to operate, and a very practical granulation recycling model, it is very popular in the PET recycling field.
3. Main Parameter
- Material: PET Flakes (≤18mm)
- Output: 500kg/hr
- Initial Moisture content: ≤2500ppm
- IV Requirement: Before pelleting≥0.7, after pelleting ≥0.65
- Power supply: 380V/ 50Hz for three phase; should be reminded, if different.
- Install power: 277KW Power consumption: 140-175KW
4. Configuration(according to your requirements)
| NO. | Description of goods | Total Power Consumption | Quantity |
| 1 | Screw Feeder ( Convey to 3000L Drying Hooper) | 1.5 kw | 1 |
| 2 | CSG 3000 Dehumidifying Dryer | 96 kw | 1 |
| 3 | Screw Feeder (Convey to SJ100 Extruder) |
1.5 kw | 1 |
| 4 | SJ 120 Single Screw Extruder | 135 kw | 1 |
| 5 | Cooling bath | - | 1 |
| 6 | Air Dryer | 1.5 kw | 1 |
| 7 | Pelletizer | 5.5 kw | 1 |
| 8 | Vibrating Screen | 0.25 kw x 2 | 1 |
| 9 | Crystallizer | 35.5 kw | 1 |
| Total | 277 kw | ||
