CE Certificate 100KW 220v 380v Honeycomb Dryer
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | JIN MACHINE |
| Certification: | CE Certificate |
| Model Number: | S-jin-1000 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard wooden frame and wooden case is available for Jin Machine Excellent Rigid Packaging drying dryer for plastic recycling |
| Delivery Time: | 40 work days |
| Payment Terms: | T/T, L/C, D/A, D/P, Western Union, MoneyGram |
| Supply Ability: | 10 sets per month |
|
Detail Information |
|||
| Product: | Honeycomb Dryer | Application: | Plastic ( PE, PET, TPU, PA...) |
|---|---|---|---|
| Capacity: | 1000 Kg/h | Warranty: | 12 Months |
| Heater Power: | 40kw | Voltage: | 220v 380v |
| Actual Power: | 100KW | ||
| High Light: | 380v Honeycomb Dryer,100KW Honeycomb Dryer,CE Honeycomb Dryer |
||
Product Description
CE Certificate 100KW 220v 380v Honeycomb Dryer
Durable 100 KW Honeycomb Dryer , Plastic Dryer Machine Easy Operation
1. Product Description
CSG series is a fully automatic drying system with zeolite desiccant beds, which can be used with Hopper Bank Series and multi-hopper systems. It can adapt and automatically control operating parameters in the light of type and quantity of polymer.Compared with the traditional dryer, it saves 40% of the energy.
1. Ease of maintenance with access process, regeneration and air filters
2. Self-adaptive PID temperature control from 60℃ to 300℃
3. No use of cooling water
4. No moving or rotating internal parts
5. No need of manual control, full auto-adaptive operation
6. On-board heating unit on hopper
7. Diagnostic functions, dewpoint, heater and temperature alarm 8.Visual and audible alarms available
9. Anti-stress function protecting polymers against overheating
10. Sturdy, well proven design for extended operational life
11. Visual and audible alarms available
12. Automatic dew point control system: not switch to new desiccant bed before the dew point gets -30°C
2. Main Technical Parameters
|
Main Technical Parameters Model |
Volume(L) | Capability(kg) | Dry Fan(KW) | Rebirth Fan(KW) | Drying Heating(KW) | Rebirth Heating(KW) | Material |
| CSG-1600 | 1600 | 1000 | 7.5 | 1.5 | 36 | 18 | 304 Stainless Steel |
| CSG-3200 | 3200 | 2000 | 18.5 | 3 | 54 | 27 | 304 Stainless Steel |
| CSG-5000 | 5000 | 3000 | 22 | 4 | 63 | 36 | 304 Stainless Steel |
| CSG-8000 | 8000 | 5000 | 33 | 4 | 96 | 36 | 304 Stainless Steel |
3. Introduction of CSG plus 8000 series
This series expands CSG standard series maintaining its characteristics while offering increased production capacity.
Its advanced thermodynamics on the basis of molecular sieve trible tower design with three desiccant cartridges and three pumps technology: two to process air production and one for saturated tower regeneration.
1. High-performance 3-bed
2. Three pumps
3. Dew point -30℃ to -70℃, dewpoint monitor
4. Dedicated to large-scale production up to 1200kg/h
4 FAQ of our product
Q1: Which city are you in? How can I get to your factory? Are you a trading company or factory?
A1: We are in Zhangjiagang city, two hours driving from Shanghai. We are a factory, manufacturing mainly plastic dryer machines. We offer turnkey solutions including conveying, drying and mixing with more than 10 years experience.
Q2: Why is your prices higher than others?
A2: We offer high-end machines in our business. Welcome to our factory to have a visit. And you will see the difference.
Q3: What is your delivery time?
A3: Normally no more than 40 working days.
Q4: How to install my machines when it arrives? How much the cost?
A4: We will send our engineers to your factory to install the machines and train your staff how to operate the machines If needed. Or you can arrange engineers to study in our factory.
You are responsible for air tickets, accommodation and our engineer wage USD100/day/person.
Q5: How long time for installation?
A5: Subject to machines and the situation in your factory. If everything is ready, it will take about 2 days for dryers and 15 days for central conveying system.
Q6: How about the spare parts?
A6: We will send one year enough easy broken spare parts together with the machines for free, we suggest you buy more units to save international courier such as DHL, it is really costly.
