CE Certificate 600KG/H Dehumidified Vacuum Powder Feeder
Product Details:
| Place of Origin: | CHINA |
| Brand Name: | JIN MACHINE |
| Certification: | CE Certificate |
| Model Number: | KFJ |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 Set |
|---|---|
| Price: | Negotiable |
| Packaging Details: | Standard wooden frame and wooden case is available for Jin Machine Excellent Rigid Packaging drying dryer for plastic recycling |
| Delivery Time: | 40 work days |
| Payment Terms: | T/T, L/C, D/A, D/P, Western Union, MoneyGram |
| Supply Ability: | 10 sets per month |
|
Detail Information |
|||
| Application: | CONVEYING | Material: | 304 Stainless Steel |
|---|---|---|---|
| Output: | 600 KG/h | Warranty: | 12 Months |
| Production Period: | 40 Days | Capacity: | 150kg |
| Heater Power: | 40kw | Voltage: | 220v 380v |
| High Light: | Dehumidified Vacuum Powder Feeder,600KG/H Vacuum Powder Feeder,CE Vacuum Powder Feeder |
||
Product Description
CE Certificate 600KG/H Dehumidified Vacuum Powder Feeder
Plastic Hot Air Hopper Dryer MD - H100 , Dehumidified Air Dryer Vacuum Loader
1.Features of Hopper Dryer
♦All material contact surface are made of stainless steel to eleminate material contamination.
♦Hinged hopper construction for easy cleaning.
♦Quick release clamps for positive locking of hinged parts.
♦Sight-glass fitted to both the bowel and base.
♦Temperature controller for accurate temperature control.
♦Overheat and overload protector ar standard equipment.
2.Specifications
| MTHD MODEL | 12 | 25 | 50 | 75 | 100 | 150 | 200 | 300 | 400 | 600 |
| Capacity KG | 12 | 25 | 50 | 75 | 100 | 150 | 200 | 300 | 400 | 600 |
| Blower W | 50 | 80 | 100 | 100 | 100 | 100 | 200 | 200 | 400 | 400 |
| Heating KW | 1.6 | 2.7 | 4 | 5 | 6 | 8 | 10 | 13 | 20 | 20 |
| (Power ) V | 380/3phase | |||||||||
| (A)MM | 590 | 665 | 755 | 755 | 835 | 835 | 970 | 970 | 1300 | 1300 |
| (B)MM | 420 | 445 | 510 | 510 | 590 | 590 | 710 | 710 | 1000 | 1000 |
| (C)MM | 635 | 820 | 940 | 1180 | 1240 | 1566 | 1550 | 1970 | 1710 | 2260 |
| (D)Inch | 1.5 | 2 | 2 | 2 | 2.5 | 2.5 | 3 | 3 | 4 | 4 |
| Weight KG | 30 | 45 | 60 | 60 | 100 | 140 | 165 | 195 | 230 | 280 |
3.Safety protection
1. Compressed air protection.
If there is little or inadequate compressed air, the equipment will stop working automatically to avoid flowing in high dew point air due to the failure of conversion valve.
2. The drying temperature overrun protection.
if the temperature of drying air overrun, drying fan will stop working automatically from coagulation due to excessive heat
3. The phase sequence protection.
if the vanes' motion is reverse, vortex pump will stop working automatically.
4.the real-time reminding of air filters cleaning
if air filters are filled with dust, the equipment will immediately remind you it is time to clean them.
5. The temperature sensor break line protection.
Alarm prompt temperature sensor fault.
all the faults will be judged automatically and showed in the Siemens screen, in order to facilite customers troubleshooting.
