Diagnostic Function 800KG/H 220v 380v Desiccant Bed Dryer

Diagnostic Function 800KG/H 220v 380v Desiccant Bed Dryer

Product Details:

Place of Origin: CHINA
Brand Name: JIN MACHINE
Certification: CE Certificate
Model Number: CSG-3000

Payment & Shipping Terms:

Minimum Order Quantity: 1 Set
Price: Negotiable
Packaging Details: Standard wooden frame and wooden case is available for Jin Machine Excellent Rigid Packaging drying dryer for plastic recycling
Delivery Time: 40 work days
Payment Terms: T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 10 sets per month
Get Best Price Contact Now

Detail Information

Product: Desiccant Bed Dryer Application: Plastic ( PE, PET, TPU, PA...)
Capacity: 500-800 KG/H Warranty: 12 Months
Production Period: 40 Days Voltage: 220v 380v
High Light:

220v Desiccant Bed Dryer

,

Diagnostic Desiccant Bed Dryer

,

800KG/H Desiccant Bed Dryer

Product Description

Diagnostic Function 800KG/H 220v 380v Desiccant Bed Dryer

Grey / White Dehumidifying Desiccant Bed Dryer Diagnostic Function Long Life Span



1. Product Description of the machine



CSG series is a fully automatic drying system with zeolite desiccant beds, which can be used with Hopper Bank Series and multi-hopper systems. It can adapt and automatically control operating parameters based on type and quantity of polymer.Up to 40% energy saving in comparison with traditional dryers

1. Ease of maintenance with access process, regeneration and air filters

2. Self-adaptive PID temperature control from 60℃ to 300℃

3. No use of cooling water

4. No moving or rotating internal parts

5. No need of manual control, Full auto-adaptive operation

6. On-board heating unit on hopper

7. Diagnostic functions,Dewpoint, heater and temperature alarm 8.Visual and audible alarms available



2. Dryer Main Technical Parameters





Model

CSG-315 CSG-800 CSG-1600 CSG-3200 CSG-5000 CSG-8000
Volume(L) 315 800 1600 3200 5000 8000
Capability(kg) 200 500 1000 2000 3000 5000
Fan Power Dry Fan(KW) 3 5.5 7.5 18.5 22 33
Rebirth Fan(KW) 0.37 1.1 1.5 3 4 4
Heating Power Drying Heating(KW) 15 24 36 54 63 96
Rebirth Heating(KW) 7.5 12 18 27 36 36
Material 304 Stainless Steel 304 Stainless Steel 304 Stainless Steel 304 Stainless Steel 304 Stainless Steel 304 Stainless Steel
Heating source Electricity Electricity Electricity Electricity Electricity Electricity
Drying Material Molecular Seive Molecular Seive Molecular Seive Molecular Seive Molecular Seive Molecular Seive



3. CSG plus 8000 series introduction

This series expands CSG standard series maintaining its characteristics while offering increased production capacity.
Its advanced thermodynamics based on zeolite trible tower design with three desiccant cartridges and three pumps technology: two to process air production and one for saturated tower regeneration.



4. FAQ



Q1: Which city are you in? How can I get to your factory? Are you a trading company or factory?
A1: We are in Zhangjiagang city, two hours driving from Shanghai. We are a factory, manufacturing mainly plastic dryer machines. We offer turnkey solutions including conveying, drying and mixing with more than 10 years experience.

Q2: Why is your prices higher than others?
A2: We offer high-end machines in our business. Welcome to our factory to have a visit. And you will see the difference.

Q3: What is your delivery time?
A3: Normally no more than 40 working days.

Q4: How to install my machines when it arrives? How much the cost?
A4: We will send our engineers to your factory to install the machines and train your staff how to operate the machines If needed. Or you can arrange engineers to study in our factory.
You are responsible for air tickets, accommodation and our engineer wage USD100/day/person.


Q5: How long time for installation?
A5: Subject to machines and the situation in your factory. If everything is ready, it will take about 2 days for dryers and 15 days for central conveying system.
